7 inch TFT 50PIN 800X480 LCD Display Screen Module

SCT070005-V04 is a TFT LCD Display with 800×480 resolution Normal White Transmissive IPS Full view direction.

  • Type: TFT
  • Mode: TN
  • Product No: SCT070005-V04
  • Size: 7.0''
  • Resolution: 800*480
  • Outline Dimension: 164.9*100.0*3.4
  • Active Area: 154.21*85.92
  • Interface: Digital
  • IC: -
  • Brightness: 300cd/m2
  • Touch Screen: No
  • View Direction: -
  • Pin No: 50
  • Shape: Rectangle
Inquiry Now

Introduction:

General Specification





ItemNominal DimensionRemark
  Lcd Size7.0 inch (Diagonal)
  Driver elementa-Si TFT active matrix
  Active Area ( W×H )51.84 × 86.40mm.
  Resolution800 x 3(RGB) x 480
  Dot Pitch ( W×H )0.0642 × 0.1790mm.
  Display ModeNormal White Transmissive
  InterfaceDigital
  Active Area154.08 x 85.92mm
  Operating temperature-20 ~70ºC
  Storage temperature-30~80ºC
  LCD TypeRGB-Stripe
  Color arrangementNormal Black
  Module Size164.9 x 100.0 x 3.4mm

 Interface Definition
